Stereo-microscopes owe their popularity to their wide range and ease of use. Due to its arm design, the SZM-600A is recommended for industrial use.
Our SZM-600A microscope is equipped with a 0.7x-4.5x zoom objective, which allows stepless adjustment of magnifications from 7x to 45x with the standard SWF10x eyepiece. The eyepiece has an outstandingly large field of view: at 7x magnification, it gives a field of view of 28.6 mm. Thanks to its complex construction, it provides a contrasty image that is sharp right to the edge of the field of view. The head of the microscope can be slid up and down on a rod up to a maximum height of 380 mm, and can even be tilted sideways up to 420 mm, allowing objects of virtually any size to be placed underneath. There is 100 mm of working space under the lenses, which can be increased to 165 mm with an optional 0.5x reduction lens.
The microscope is not equipped with illumination, so the use of some form of external illumination is highly recommended. By attaching the rubber eyecups included in the package to the upper part of the eyepieces, you can exclude side scattered light, making observations more comfortable.
The binocular head is tilted at 45° and its eye relief is freely adjustable between 55-75 mm. Dioptric correction is provided on both sides. The basic package also includes a sturdy covering foil to protect the microscope from dust when not in use.
For digital recording of what you see in the microscope, we offer members of our ToupCam camera series - to fit these into the microscope, you will need a 30mm adapter, which is also available from our shop for an extra charge.
